Picture/Display
|
ture/Display
• Diagonal screen size: 54.6 inch / 138.7 cm
• Panel resolution: 1920 x 1080p
• Optimum resolution: 1920 x 1080 @ 60 Hz
• Brightness: 700 cd/m²
• Response time (typical): 8 ms
• Dynamic contrast ratio: 500,000:1
• Aspect ratio: 16:9
• Viewing Angle (H / V): 178 / 178 degree
• Pixel pitch: 0.63 x 0.63 mm
• Display colours: 1.07 B
• Picture enhancement: 3/2 - 2/2 motion pull down,
3D Combfilter, Motion compens. deinterlacing,
Progressive scan, 3D MA deinterlacing, Dynamic
contrast enhancement
• Contrast ratio (typical): 1200:1
|
|
Supported Display Resolution
|
Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75 Hz
800 x 600 56, 60, 72, 75 Hz
1024 x 768 60 Hz
1280 x 768 60 Hz
1280 x 800 60 Hz
1280 x 1024 60 Hz
1360 x 768 60 Hz
1366 x 768 60 Hz
1440 x 900 60 Hz
1600 x 1200 60 Hz
1920 x 1080 60 Hz
1920 x 1200 60 Hz
• Video formats
Resolution Refresh rate
480i 60 Hz
480p 60 Hz
576p 50 Hz
576i 50 Hz
720p 50, 60 Hz
1080i 50, 60 Hz
1080p 50, 60 Hz
3840 x 2160 30Hz
|
|
Connectivity
|
Video input: Component (RCA), Composite
(RCA), DVI-D, HDMI (x 2), VGA (Analogue DSub), DisplayPort (1.2)
• Video output: DisplayPort, DVI-I, VGA (via DVI-I)
• Audio input: 3.5 mm jack, Audio Left/Right (RCA)
Audio output: Audio Left/Right (RCA), External
speaker connector
• External control: IR (in/out) 3.5 mm jack, RJ45,
RS232C (in/out) 2.5 mm jack
• Other connections: OPS
|
|
Convenience
|
Signal Loop Through: RS232, VGA, DisplayPort,
DVI, IR Loop through
• Ease of installation: Carrying Handles, Smart Insert
• Energy-saving functions: Ambient light sensor,
Smart Power
• Network controllable: RS232, RJ45, Card OPS
RS232, One Wire (HDMI-CEC)
• Placement: Landscape (24/7), Portrait (24/7)
• Screen-saving functions: Pixel Shift, Low Bright
• Tiled Matrix: Up to 10 x 10
• Control software: SICP / CMND & Control
• RJ45 hub: 2 ports
|
|
Dimensions
|
• Bezel thickness: 1.8 mm (A-A)
• Bezel width: 0.9mm (Even Bezel)
• Set dimensions (W x H x D):
1211.4 x 682.2 x 98.5 mm
• Set dimensions in inch (W x H x D):
47.69 x 26.86 x 3.88 inch
• Product weight: 24.35 kg
• VESA Mount: 400 x 400 mm
|
|
Operating conditions
|
• Temperature range (operation): 0 ~ 40 °C
• Temperature range (storage): -20 ~ 60 °C
• Altitude: 0 ~ 3000 m
• Relative humidity: 20 ~ 80 %
• MTBF: 50,000 hour(s)
|
|
Power
|
Consumption (On mode): 168W
• Standby power consumption: <0.5 W
|
|
Sound
|
• Built-in speakers: 2 x 10 W (RMS)
|
|
Accessories
|
• Included accessories: Remote Control, Batteries
for remote control, AC Power Cord, RS232 cable,
Quick start guide, Edge alignment pins, Edge
alignment plates
|
|
Miscellaneous
|
• On-Screen Display Languages: Arabic, Simplified
Chinese, Traditional Chinese, English, French,
German, Italian, Japanese, Polish, Russian, Spanish,
Turkish
• Regulatory approvals: CE, UL/cUL, CB, GOST,
EPEAT, FCC, Class B
• Warranty: 3 year warranty
|
