מצלמה
|
Image Sensor
1/2.7" Progressive Scan CMOS
Min. Illumination
2 mm: Color: 0.01 Lux @ (F2.25, AGC ON), B/W: 0 Lux with IR
2.8 mm and 4 mm: Color: 0.01 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Max. Resolution
1920 × 1080
Shutter Time
1/3 s to 1/100, 000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
|
|
עדשה
|
Lens Type
Fixed focal length, 2, 2.8, and 4 mm optional
Focal Length & FOV
2 mm, horizontal FOV 137.2°, vertical FOV 80.1°, diagonal FOV 157.4°
2.8 mm, horizontal FOV 113.4°, vertical FOV 59.8°, diagonal FOV 135.6°
4 mm, horizontal FOV 91.5°, vertical FOV 46.1°, diagonal FOV 109.8°
Aperture
2 mm: F2.25
2.8 mm: F1.6
4 mm: F1.6
Iris Type
Fixed
Lens Mount
M12
|
|
ווידאו
|
Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile/Main Profile/High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR/VBR
Scalable Video Coding (SVC)
Yes
Region Of Interest (ROI)
1 fixed region for main stream
|
|
רשת
|
Simultaneous Live View
Up to 6 channels
API
Open Network Video Interface, ISAPI
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X(-W model does not support), QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS, SNMP, PPPoE
User/Host
Up to 32 users. 3 levels: administrator, operator and user
Security
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage
NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Client
iVMS-4200, Hik-Connect
Web Browser
Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
|
|
תמונה
|
Wide Dynamic Range (WDR)
120 dB
Day/Night Switch
Day, Night, Auto, Schedule
Image Enhancement
BLC, 3D DNR
Image Settings
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser.
|
|
ממשק
|
Built-In Microphone
Yes
Built-In Speaker
Power: 1 W. Max. sound pressure level: 10 cm: 91 dB.
On-Board Storage
Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
Reset Key
Yes
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
|
|
סביבת עבודה
|
Basic Event
Motion detection, video tampering alarm, exception
Smart Event
Line crossing detection, intrusion detection
Linkage
Upload to FTP/memory card, notify surveillance center, send email, trigger recording, trigger capture, audible warning
|
|
כללי
|
Power
-I:
12 VDC 25%, 0.49 A, max. 5.8 W, 5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.19 A to 0.12 A, max. 6.8 W
-IW:
12 VDC 25%, 0.66 A, max. 7.9 W, 5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.25 A to 0.16 A, max. 8.9 W
Language
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Storage Conditions
-10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions
-10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)
Dimension
2 mm: 102.9 mm × 65.2 mm × 28.8 mm (4.1" × 2.6\" × 1.1\")
2.8 mm and 4 mm: 102.9 mm × 65.2 mm × 32.6 mm (4.1 × 2.6\" × 1.3\")"
Package Dimension
150 mm × 125 mm × 99 mm (5.9" × 4.9" × 3.9")
Approx. 115 g (0.3 lb.)
With Package Weight
Approx. 330 g (0.7 lb.)
|
|
אודיו
|
Environment Noise Filtering
Yes
Audio Sampling Rate
8 kHz/16 kHz
Audio Compression
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC
Audio Bit Rate
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC)
|
|
DORI
|
DORI
2 mm: D: 30.3 m, O: 12.0 m, R: 6.1 m, I: 3.0 m
2.8 mm: D: 37.3 m, O: 14.8 m, R: 7.5 m, I: 3.7 m
4 mm: D: 52.9 m, O: 21.0 m, R: 10.6 m, I: 5.3 m
|
|
תאורה
|
Supplement Light Range
Up to 10 m
IR Wavelength
850 nm
Smart Supplement Light
Yes
|
|
Wi-Fi
|
Encryption Mode
-IW: 64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA2-PSK
Wi-Fi Protocol
-IW:
802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM
Frequency Range
-IW:
2.412 GHz - 2.472 GHz
Channel Bandwidth
-IW:
20/40 MHz
Modulation
-IW:
802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM
Transfer Rate
-IW:
11b/g: 54 Mbps
11n: up to 150 Mbps
Wireless Range
-IW: Up to 50 m (The performance varies based on actual environment)
|
|
PIR
|
PIR Angle
Horizontal: 90°, vertical: 80°
PIR Range
Up to 8 m
|
|
תקנים
|
EMC
FCC (47 CFR Part 15, Subpart B)
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014)
RF
-IW:
FCC ID (FCC Part 15.247(BT or 2.4G));
CE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN 300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G))
Safety
CB (IEC 62368-1: 2014+A11)
CE-LVD (EN 62368-1: 2014/A11: 2017)
Environment
CE-RoHS (2011/65/EU);
WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
|
