חיבור ממשק
|
USB3.0, *300-350MB/s throughput
USB2.0, *40MB/s throughput
|
ממשק קלט
|
1 MCX interface (can convert to BNC interface)
|
קלט SDI
|
1 1080p/60Hz SD/HD/3G-SDI
|
קלט אודיו SDI
|
1 embedded SDI audio
|
קלט SDI פורמט
|
SD/HD/3G-SDI, SMPTE-259 / 274 / 296 / 372 / 424 / 425 / 292
|
פלט פורמטים
|
Resolution: 640×480 / 640×360 / 720×480 / 720×576 / 768×576 / 856×480 / 960×540 / 1024×576 / 1280×720 / 1920×1080
Frame rate: 25 / 29.97 / 30 / 50 / 59.94 /60 fps
|
Video Sampling Rate
|
SDI: 270Mb/s, 1.485Gb/s, 2.97Gb/s
|
אודיו ווידאו
|
It meets the standards of UVC (USB video class) and UAC (USB audio class)
|
Output Color Space
|
YUY2, RGB24
|
Color Space Conversion
|
Hardware Color Space Conversion
|
Up/down Scaling
|
Hardware Up/down Scaling
|
Image Adjustment
|
The image adjustment of brightness, contrast, hue, saturation.
|
תאימות מערכות הפעלה
|
Windows 7/8/8.1/10/2008/2008 R2/2012 (x86 & x64)
Linux (Ubuntu 12.04–16.10, CentOS 7)
OS X 10.9–10.11
macOS 10.12
Chrome OS
|
תאימות מערכת
|
Windows Media Encoder (Windows)
Adobe Flash Media Live Encoder (Windows, OS X)
Real Producer Plus (Windows)
VLC (Windows, OS X, Linux)
QuickTime Broadcaster (OS X)
QuickTime Player (OS X)
Wirecast (Windows, OS X) and etc.
|
תאימות פיתוח ממשק
|
DirectShow (Windows), DirectSound (Windows), V4L2 (Linux), ALSA (Linux)
|
זכרון לוח
|
64MB DDR2, the work rate is 300 MHz, the bit width is 16 bits
|
עדכון
|
Firmware can be upgraded
|
מידות
|
92.2x 40.2 x 12.3 (L/W/H, mm)
|
